模型

Model

單位Unit

ACOT-10

ACOT-20

ACOT-30

ACOT-40

ACOT-50

ACOT-75

ACOT-100

ACOT-150

溫控范圍

Temp Range

℃

常溫-300℃ Normal temperature-300℃

溫控精度

Temp.Control Accuracy

PID±1℃

電源

Power Supply

AC3∮380V 50HZ3P+E（5M）

傳熱媒體

Heat Transfer Medium

導熱油 Qil

冷卻方式

Cooling Method

間接冷卻Indirect Cooling

膨脹箱容量①

Expansion Tank Capacity

L

24

24

28

55

55

(100)

(150)

(250)

加熱能量

Heating Capacity

KW

18

18/24

24/36

36/50

40/60

50/75

80/100

100/150

泵浦功率

Pump Power

KW

0.75

1.5

2.2

3.0

4.0

5.5

7.5

11.0

泵浦流量②

Pump Folw

L/MIN

1.5

1.5

10

12.5

16

12.5(18)

25(30)

12.8(18)

泵浦壓力

Pump Pressure

KG/CM2

2.2

2.2

2.8

3.0

3.2

5.0(4.0)

5.0(4.8)

8.7(7.0)

最大電力消耗

Power Supply

KW

13

20

28

40

50

62

132

162

警報功能

alert Function

缺相/缺水/超溫/過載 Pump Reversal/Oil Shortage/Overheating/Overload

冷卻水配管

Cooling Water Pipe

INCH

1/2

1/2

1/2

1/2

1/2

1/2

3/4

3/4

循環油配管

Circulati onwater Pipe

INCH

3/4

3/4

1

1-1/4

1-1/4

1-1/2

2

2.5

外型尺寸

Size(L*W*H)

MM

1150*500*1000

1150*500*1000

1450*580*1250

1600*630*1200

1600*550*1200

1600*550*1200

1600*600*1400

1600*600*1400
